Base frame:

• Bottom Frame 100mm x 50mm "C" channel.
• Stiffener Bottom 75 x 40 mm "C" channel.

Side and End Walls:

• Paneling Outside especially GI Sheet (Galvanized Sheet).
• Internal Wall Panelling 8mm MDF OSL Sheet.
• All steel sheets used tested for corrosion resistance.
• All gaps sealed at edges & at seams, bottom etc for preventing ingress of moisture.

Flooring Systems:

• Bottom Flooring 18mm M.R. Grade(Moisture Resistant plywood) ply (fixed by means of self-tapping screws).
• PVC Vinyl Carpet fixed on the panel.

Roof:

• Roof Outside especially GI Sheet ( Galvanized Sheet) -1.2mm thick Properly Sloped and watertight.
• False Ceiling 8mm MDF - Plane White.

Paint:

• Outside Painting Phosphate the Cabin and painting with 1 coat of Epoxy primer with Two Coat of Epoxy Paint.

Insulation:

• Insulation Glass Wool density of 16kg./m3 RB glass Wool Insulation (Side Wall -50mm), (Ceiling 50 mm)

Main Entry Door:

• Door insulated with for locking agreement, Hold draft & Handles.

Aluminum Windows:

• Aluminum Windows Double Shutter Sliding Aluminium Powder Coated Windows ASIS With Safety Grills.

Electrical Systems and Wiring:

• All wiring shall be concealed type & shall be of copper wire.
• All electrical fittings in the Portable Cabin shall be 220-240V, AC 50Hz Tubes Door Light, Fan. Switches, Sockets, Telephone, Air Conditioners Point (MCB) (All Type of Window Air Conditioning Systems as desired upon can be installed.
• Earthling Point shall be provided for Safety.
